Chapter 5 Installation
Mini-Switch LB 471
56
5.2.6 Installation of Super-Sens
with Radial Irradiation
The radial radiation window, located on the side, covers the sensi-
tive area of the detector. The radiation window must face the
source.
Figure 22:
Install Super-Sens
with lateral irradiation on
container
Bracket
provided by
customer
Radiation path
