Chapter 15 Technical Drawings
Mini-Switch LB 471
15.2.2 Detector Holder for GM Detector and NaI Counter
This holder comprises two clamps mounted on an angle. It may be used optionally instead of
the fastening clamps. The advantage is that this angle can be welded or screwed directly onto
the bracket. Moreover, the holder is very robust and can be used in if little space is available.
All metal parts of this fastening set are made of stainless steel.
Point detector without water cooling
Point detector with water cooling
