Chapter 3 Parameters
Mini-Switch LB 471
For the limit switch to continue working normally, you have to turn
off the test generator after the test.
To be on the safe side, the test generator will be turned off auto-
matically after 20 minutes.
The test generator is also disabled if the limit switch is locked by
entering the password.
Test error relay
Test error relay
(Only in the professional mode)
Push the Enter button to enable and disable the error relay.
Push Clear to exit the test.
Test alarm relay
Test alarm relay
(Only in the professional mode)
Push the Enter button to enable and disable the alarm relay.
Push Clear to exit the test.
Test warning relay
Test warning relay
(Only in the professional mode)
Push the Enter button to enable and disable the warning relay.
Push Clear to exit the test.
Test display
Test display
(Only in the professional mode)
Push the Enter button to enable the display test. The display
shows a number of patterns by means of which the function of
each pixel or element can be recognized.
Push Clear to exit the test.
