Chapter 7 Shielding Installation
Mini-Switch LB 471
Figure 34:
Installation proposal
for shielding
Figure 35:
Example of
flange installation
Flange installation
Installation on pedestal
LB 7440
LB 7445
LB 7442
LB 7445
LB 7444
h
90
120
161
