Place the vehicle on a central stand. Drain the engine oil (see
Chapter 4 Maintenance).
Removing the saddle
Remove the left-hand and right-hand saddle screws. Remove
the saddle by pulling it towards the back of the vehicle.
Removing the fuel tank
To remove the tank together with the deflectors, unscrew the
left-hand and right-hand screws fixing it to the radiator.
Remove the central screw as shown in the figure and disengage
the tank.
Close the fuel cock, remove the fuel line and take off the reser-
voir.
5
6 - Engine Release 01 Date 09/2007
