1 - General information Release 01 Date 09/2007
HOW TO CONSULT THE MANUAL
Arrangement of subjects
The manual is divided into chapters that cover the main sub-
assemblies of the vehicle. To make the different chapters easy
to find, the pages of each chapter bear a reference mark that is
aligned with the related title in the general contents.
Description of operations
The removing, fitting and checking operations described in the
manual are accompanied by pictures (drawings or pho-
tographs).
The pictures contain symbols referring to procedures, special
tools and other information. Refer to the key to the symbols for
a description of their meanings.
The procedures are arranged sequentially, step by step.
EXAMPLE
Whenever a specific tightening torque is needed, begin by ap-
plying a standard tightening torque (e.g. 10 N·m), then proceed
with the tightening by rotating the part by a predetermined angle
(e.g. 30°).
PURPOSE OF THE MANUAL
This manual is chiefly intended for qualified Betamotor dealers and mechanics. A mechanic should not expect to find all
the information he requires in a manual. Anybody who uses this manual should have a working knowledge of the princi-
ples of mechanics and of motorcycle repairing techniques. Performing repairs or maintenance operations without this
knowledge may render the vehicle unusable and even dangerous.
Updates
Betamotor is committed to continually improving its products. Any significant changes made to the specifications and pro-
cedures contained in this manual will be made known to official dealers and will be included in future editions of the man-
ual. All the information, instructions and technical data provided in this manual were up-to-date when the manual was ap-
proved for print. Betamotor reserves the right to make changes to the manual at any time, without notice and without in-
curring any obligations.
30°
10 N·m
