3 - Tighening torques, specifications, recommended products, Homologation E3 Release 01 Date 09/2007
SPECIFICATIONS - FRAME
TIGHTENING TORQUES
4 fork foot screws M6 10 N·m
Front brake caliper M8 CH10 Loctite 243 + 30 N·m
Front brake disc M6 Loctite 243 + 15 N·m
Rear brake disc M8 CH10 Loctite 243 + 20 N·m
Upper fork plate clamping screws M8 CH10 20 N·m
Lower fork plate clamping screws M8 CH10 20 N·m
Rear wheel spindle flange nut M20x1.5 CH27 90 N·m
Swingarm pin hexagonal nut M16x1.5 CH19 100 N·m
Handlebar clamp screws M8 CH10 20 N·m
Handlebar support screws M10 TCEI Loctite 243 + 40 N·m
Upper shock absorber screw M10x1.25 Loctite 243 + 80 N·m
Lower shock absorber screw M12 Loctite 243 + 80 N·m
Chain sprocket screws, special screw M8 10.9 Loctite 243 + 25-30 N·m
Brake pedal screw M8 CH10
Brake pedal ball joint screw M6 Loctite 243 + 10 N·m
Engine fixing screws M10x1.25 CH14 45 N·m
Other frame screws M6 10 N·m
M8 25 N·m
M10 45 N·m
Other frame flange nuts M6 15 N·m
M8 30 N·m
M10 50 N·m
