Removing the intake sleeve
Disconnect the carburettor intake sleeve.
Rear frame
Remove the two screws 1 to the left and right of the rear frame
and loosen the two screws 2.
Disconnecting the electrical system
Disconnect all the electrical connections, cutting the wire clamps
where necessary.
Tipping over the rear frame
It is now possible to overturn the rear frame towards the front of
the vehicle.
To avoid scratching the rear mudguard, place a soft cloth
over the handlebars.
Disconnecting the rear
brake pump
Unscrew the two screws 1 to
disengage the rear brake
pump from the frame.
8
Workshop manual RR 4T - 400 - 450 - 525
1
2
1
