Removing the right-hand side panel
To gain access to the silencer fixing screws, it is first necessary
to remove the right-hand side panel.
Pay attention to the plastic catches between the side pan-
el and the mudguard.
Removing the silencer
Loosen the two screws shown in the figure.
Remove the spring that fastens the silencer to the exhaust pipe.
Be careful to avoid injury from the spring.
Draining the cooling system
Place a container as shown in the figure to collect the coolant.
Unscrew drain screw 1 on the cylinder front.
Remove the radiator cap in the upper part of the system and al-
low the coolant to drain completely.
Refit the drain screw using, if necessary, a new seal.
6
Workshop manual RR 4T - 400 - 450 - 525
