22
Workshop manual RR 4T - 400 - 450 - 525
DIGITAL RPM INDICATOR (RR4T Euro 3 version)
SCROLL PUSHBUTTON
The instrument panel has a pushbutton A which changes and sets the main functions.
WARNING LIGHTS
The instrument panel has three warning lights. Warning light B, GREEN, indicates turn indicators have been activated.
Warning light C, BLUE, indicates when the high-beam light is ON.
Warning light D, YELLOW, indicates the reserve (not activated)
Important:
When cleaning operation using a high-pressure water jet cleaner, avoid aiming the jet to the digital instrument panel.
B
A
C
D
