6
Removing the headlight grille
Release the two rubber bands Q as shown in the figure, pull out
the headlight and remove grille R.
Workshop manual RR 4T - 400 - 450 - 525
Q
R
05_Inghilterra_059311 27-12-2007 18:14 Pagina 6
