2. Front Panel Operation
2
.1 Front Panel Overview
(1) Power switch:
Turns on the main power to the power supply.
(2) Display:
192x32 Graphic LCD Module
(3) Current setting :
Press to set up the current limit.
(4) Voltage setting :
Press to set up the output voltage.
(5) Dot/Local :
This button is applied as a decimal point. It is also used to revert back to
LOCAL mode when the unit is in REMOTE mode. If the instrument is in
LOCK mode, press this button to unlock.
(6) ESC/CLR :
Press this button to clear up numerical settings. It is also used to go
1
15
2 3 4 5
1214 13
76 8 109 11
XLN60026
600V / 2.6A 1.56kW Programmable DC Power Supply
