4.6 State Bit Definition
When “STATE?” command is used, the system will return three bytes in the
order as shown below.
The
definition of each bit is described in the following:
byte 0: bit 7 OVP on/off status
b
it 6 OCP on/off status
b
it 5 OPP on/off status
b
it 4 CC to CV on/off status
b
it 3 CV to CC on/off status
b
it 2 output on/off status
b
it 1 LCD back light on/off status
b
it 0 reserved status
byte 1: bit 7 OVP occur flag
b
it 6 OCP occur flag
b
it 5 OPP occur flag
b
it 4 CC to CV occur flag
b
it 3 CV to CC occur flag
b
it 2 AC detect low occur flag
b
it 1 OTP occur flag
b
it 0 reserved
byte 2: bit 7 - 0 reserved
