4.8.3 Error Message of Series/Parallel Connection
If the RS485 wiring is wrong or the signal is not correct, the Master will
display the following message in the screen for searching Slaves:
If more than one Master is being set in the series/parallel operation mode, the
following message will be displayed.
If one of the power supplies is set to different series/ parallel operation mode,
the following message will appear on-screen:
After finishing setting procedure, if the Master cannot have a communication
with one of the three Slaves, the Master will present the following error
message (Slave A in this example).
After finishing the setting procedure, if a Slave receives only the output
command sent by the Master but does not receive the synchronization signal, it
will present the following error messages. The error message “SYNC ON” is
shown when the slave is not receiving the synchronous output ON signal. The
To Next Page
