34
by turning the rotary knob. Press
and the cursor appears in response;
press
or
to move the cursor to the digit you want to change
and turn the knob to increase or decrease the output voltage value at the cursor.
The changes of the voltage setting and the output voltage will immediately
apply.
2.11 Timer Function
When the “Timer Setting” function is ON, it will activate the timer. After the
timer setting is made, return to the main screen. Set up the output current &
voltage and press to output. The screen will show the countdown
of the timer. Once it reaches zero, the supply will turn off the output
automatically.
2.12 Parallel Mode Setting
The power supplies can be connected in parallel (up to 4 units of the same
model) to increase the power output capability and to increase the total output
current. With 4 units connected, up to 6240 W maximum can be output.
Below is a diagram showing 4 units connected in parallel.
