7.2 Assembly of Output Protective Cover
(XLN6024/XLN8018/XLN10014)
Safety regulation requests protective cover when the output voltage is higher
than 45 VDC. Therefore, there are protective covers for the output connectors
for the XLN6024/XLN8018/XLN10014. Refer to the following figure for the
assembly/disassembly of the output protective cover.
Step 2
2
1
Step 1
1
3
Step 3
