BK Precision XLN3640 - OCP Calibration

104
MID2
2.08
1.872 ~ 2.288
MID3
3.468
3.1212 ~ 3.8148
Hi
4.94
4..446 ~ 5.434
XLN15010
Function Setting Range of transformation value
Lo
0.5408
0.04 ~ 0.5949
MID1
1.3697 1.2327 ~ 1.5067
MID2
4.16
3.744 ~ 4.576
MID3
6.9368
6.2431 ~ 7.6305
Hi
9.88
8.892 ~ 10.868
6. If the values are not consistent with your measurements, there
might be issues with the hardware and will need to be inspected
by a trained technician.
7. Once calibration is finished, the values will be stored into the
internal flash memory and return to the calibration menu.
5.5 OCP Calibration
Follow the step by step instructions below for OCP calibration.
1. Press in the calibration menu to enter OCP calibration
menu.
2. Press to access the OCP calibration procedure for “Lo”.
