37
If more than one Master is being set to parallel mode, the following message
will be displayed.
After the master is configured, if it cannot communicate with one of the slave
supplies, the following error message will be displayed (example showing
Slave A)
After finishing the set up, if a Slave receives only the output command sent by
the Master but does not receive the synchronization signal, it will present the
following error messages. The error message “SYNC ON” is shown when the
slave is not receiving the synchronous output ON signal. The error message
“SYNC OFF” is shown when the slave is not receiving the synchronous output
OFF signal.
L
F
L
=
:
=FF
L
=
,
L
=
FF
L
L
!!!
LL L
::
