D. According to voltage value displayed on DVM, fill in the values
for their corresponding functions and press ENTER. If any DVM
read-back value at each voltage function does not fit with the
following table below, please inspect the hardware.
XLN3640
Function
Setting
Value
Range of Read-Back Value
Lo 1.8V 1.5 - 2.0 V
MIDL 12V 10 - 13 V
MIDH 24V 21 - 25 V
Hi 32.4V 31 - 34 V
XLN6024
Function
Setting
Value
Range of Read-Back Value
Lo
3V
2.4 - 3.6 V
MIDL
20V
18 - 22 V
MIDH
40V
36 - 44 V
Hi
57V
53 - 61 V
XLN8018
Function
Setting
Value
Range of Read-Back Value
Lo
4V
3.6 - 4.4 V
MIDL
26V
23.5 - 28.5 V
