32
(23) 5V/1A Output:
XLN series offers an extra output with a constant output voltage of 5 V
and the maximum output current of 1 A. This extra power supply can be
switched on or off under the “System Setting” menu.
(24) USB :
USB interface connector.
(25) EXT CTL:
Models XLN3640/XLN6024/XLN8018/XLN10014 offer the capability
of setting the output voltage/current by adjusting an external input
voltage/resistance. The range of the external input voltage is 0 - 10 VDC
or 0 - 5 VDC, which corresponds to the output voltage of 0 - 36 V for
XLN3640, 0 - 60 V for XLN6024, 0 - 80 V for XLN8018, and 0 - 100 V
for XLN10014 and corresponding to the output current of 0 - 40 A for
XLN3640, 0 - 24 A for XLN6024, 0 - 18 A for XLN8018, and 0 - 14.4 A
for XLN10014. The range of the external resistance is 0 - 5 K ohm
which corresponds to the output voltage of 0 - 36 V for XLN3640, 0 -
60V for XLN6024, 0 - 80 V for XLN8018, and 0 - 100 V for XLN10014
and corresponding to the output current of 0 - 40 A for XLN3640, 0 - 24
A for XLN6024, 0 - 18 A for XLN8018, and 0 - 14.4 A for XLN10014.
(26) RS485:
While in series or parallel connection or multi-unit series connection
(CHAIN), RS485 interface can be used for communication and
synchronization between master and slave.
(27) Protection cover of the RMT/LCL Sense connector
(XLN6024/XLN8018/XLN10014):
WARNING:
When the RMT/LCL Sense is not activated and/or not
used, the protection cover must be covered
. To prevent
electric shock, do not dissemble this protective cover.
(28) Protection cover of the output leads
(XLN6024/XLN8018/XLN10014):
