No. Description Unit Setting range Chapter
Speed controller
766
Actual Speed Source - Selection
8.4.15
System bus
900
Node-ID - -1 ... 63
7.5
903
Baud-Rate - Selection
7.4
904
Boot-Up Delay ms 3500 ... 50000
7.8.4
918
SYNC-Identifier - 0 ... 2047
7.8.2
919
SYNC-Time ms 0 ... 50000
7.9.2
921
RxSDO1-Identifier - 0 ... 2047
7.9.5
922 TxSDO1-Identifier - 0 ... 2047
7.9.5
923
SDO2 Set Active - Selection
7.9.5
924
RxPDO1 Identifier - 0 ... 2047
7.11.1
925
TxPDO1 Identifier - 0 ... 2047
7.11.1
926
RxPDO2 Identifier - 0 ... 2047
7.11.1
927
TxPDO2 Identifier - 0 ... 2047
7.11.1
928
RxPDO3 Identifier - 0 ... 2047
7.11.1
929 TxPDO3 Identifier - 0 ... 2047
7.11.1
930 TxPDO1 Function - Selection
7.11.2
931
TxPDO1 Time ms 0 ... 50000
7.11.2
932
TxPDO2 Function - Selection
7.11.2
933
TxPDO2 Time ms 0 ... 50000
7.11.2
934
TxPDO3 Function - Selection
7.11.2
935
TxPDO3 Time ms 0 ... 50000
7.11.2
936
RxPDO1 Function - Selection
7.11.2
937 RxPDO2 Function - Selection
7.11.2
938
RxPDO3 Function - Selection
7.11.2
939
SYNC Timeout ms 0 ... 60000
7.11.3
941
RxPDO1 Timeout ms 0 ... 60000
7.11.3
942
RxPDO2 Timeout ms 0 ... 60000
7.11.3
945
RxPDO3 Timeout ms 0 ... 60000
7.11.3
946
TxPDO1 Boolean1 -
Selection
7.11.5.1
947 TxPDO1 Boolean2 - Selection
7.11.5.1
948 TxPDO1 Boolean3 - Selection
7.11.5.1
949
TxPDO1 Boolean4 -
Selection
7.11.5.1
950
TxPDO1 Word1 -
Selection
7.11.5.1
951
TxPDO1 Word2 -
Selection
7.11.5.1
952
TxPDO1 Word3 -
Selection
7.11.5.1
953
TxPDO1 Word4 -
Selection
7.11.5.1
954
TxPDO1 Long1 -
Selection
7.11.5.1
955 TxPDO1 Long2 - Selection
7.11.5.1
956
TxPDO2 Boolean1 -
Selection
7.11.5.1
957
TxPDO2 Boolean2 -
Selection
7.11.5.1
958
TxPDO2 Boolean3 -
Selection
7.11.5.1
959
TxPDO2 Boolean4 -
Selection
7.11.5.1
960
TxPDO2 Word1 -
Selection
7.11.5.1
961
TxPDO2 Word2 -
Selection
7.11.5.1
962 TxPDO2 Word3 - Selection
7.11.5.1
963 TxPDO2 Word4 - Selection
7.11.5.1
964
TxPDO2 Long1 -
Selection
7.11.5.1
965
TxPDO2 Long2 -
Selection
7.11.5.1
966
TxPDO3 Boolean1 -
Selection
7.11.5.1
967
TxPDO3 Boolean2 -
Selection
7.11.5.1
968
TxPDO3 Boolean3 -
Selection
7.11.5.1
969
TxPDO3 Boolean4 -
Selection
7.11.5.1
972 TxPDO3 Word1 - Selection
7.11.5.1
973
TxPDO3 Word2 -
Selection
7.11.5.1
