Bosch EPS 815 - Extent of Delivery; Special Accessories

1 689 979 672 2012-06-26| Robert Bosch GmbH
Product description | EPS 807 / 815 | 29 en
�.� Extent of delivery
Quantity Designation Order no. Use
1 Basic test bench 807 or 815 0 683 807 XXX or
0 683 815 XXX
1 Guide tube complete 1 688 020 140 for the measuring device holder
1 Four socket strips 1 684 485 172
1 Accessory set 1 687 010 126 For flushing distributor injection pumps
4 Hosepipes 1 680 711 035 For accessory set 1687010126
1 Hosepipe 1 680 712 151 For calibration fluid (supply)
1 Hosepipe 1 680 712 051 For calibration fluid (reflow)
1 Box spanner, A/F 11 1 687 950 058 For nozzle holder
1 Sliding tee bar 1 683 000 000 For graduated disc
1 Screwdriver, A/F 8 1 907 950 008
1 Screwdriver, A/F 10 1 907 950 009
1 Electric connecting cable 1 684 448 290 For multi-flow magnet, start/ stop magnet
1 Electric connecting cable 1 684 465 363 For temperature sensor
4 Damping plates 1 682 388 043 For test bench installation
1 Non-floating coupling pursuant to ISO 1 686 401 026
1 Shock protection 1 685 510 148 For coupling
1 Set of small components (inlet unions,
inlet-union screws, seal rings, etc.)
–
2 Sets of technical documentation –
�.4 Special accessories
Designation Order no. Use
Supplementary-equipment Set 1 687 001 977 lubricating-oil supply
Accessory set 1 687 005 018
1 687 005 019
1 687 005 020
1 687 005 021
1 687 005 022
1 687 005 023
basic equipment for 8 cyl. pumps
A-pump set in combination with 1687005018
M-MW pump set (in combination with 1687005019 set
P-pump set
distributor pump set in combination with 1687005018
H/R-pump set
Measuring equipment 0 683 802 001
0 683 822 001
0 683 812 001
0 683 824 001
KMA802 Electronic quantity measurement system
KMA822 Electronic quantity measurement system with trolley
MGT 812 glass gauge support (12 glasses)
MGT 824 glass gauge support (24 glasses)
Rotating pin 1 683 105 083 safety pin with sliding sleeve
Tester set VPM 844 1 687 002 844 To test VP 29, 30 and 44 (only for EPS815)
Tester set CRS 845H 1 687 002 845 To test CR high-pressure pumps (only for EPS815)
Tester set CRI 846H 1 687 002 846 To test PKW CR injectors (only for EPS815)
Tester set CRI/CRIN 848H 1 687 001 848 To test PKW CR injectors (only for EPS815)
Tester set CAM 847
with Adapter
1 687 001 847 To test UI/UP injectors (only for EPS815)
Tester set CAM 847
without Adapter
1 687 001 849 To test UI/UP injectors (only for EPS815)
