1 689 979 672 2012-06-26| Robert Bosch GmbH
44 | EPS 807 / 815 | Tightening torquesen
8.4 Drive Clutch
8.4.1 Drive clutch 1686401024
Tightening torque [Nm]
EPSside 95 +2
Pump side 35 +2
8.4.2 Drive clutch 1686401026
Tightening torque [Nm]
EPSside 95 +2
Pump side 60 ±2
8.4.� Tightening torques for the tensioning bolt
Size Tightening torque [Nm]
M 8 x 65 DIN 912-12.9 15 +2
M 10 x 80 DIN 912-12.9 30 +2
M 12 x 80 DIN 912-12.9 60 +5
9. Technical Data
9.1 Dimensions and models
Property EPS807 EPS815
MGT KMA MGT KMA
Overall dimensions:
Length
Height max.
Width
Weight approx.
mm
mm
mm
kg
2260
1565
660
1000
2260
1565
660
1000
2260
1565
660
1000
2260
1565
660
1000
Drive motor:
Basic model
Voltage
Frequency
Degree of protection pursuant to DIN 40050
Motor overload protection
Rated current at 400 V
V
Hz
°C
A
400 ± 10%
50/60
IP 54
155
16
400 ± 10%
50/60
IP 54
155
16
400 ± 10%
50/60
IP 54
155
30
400 ± 10%
50/60
IP 54
155
30
Power at the coupling:
Basic model, continuously
Basic model, approx. 2 min.
Basic model, approx. 60 sec
Speed range
Direction of rotation
KW, (n
o
)*
KW, (n
o
)*
KW, (n
o
)*
min
-1
5,8
8,9
10,7
0 – 4000
left/right
5,8
8,9
10,7
0 – 4000
left/right
10,2
15
17,5
0 – 4000
left/right
10,2
15
17,5
0 – 4000
left/right
Tachometer
Stroke counter
Overflow measurement
Voltage supply 12/24 V for start/stop
magnets
min
-1
strokes
l/h
A
0 – 6400
0 – 5000
0 – 260
7
0 – 6400
0 – 5000
0 – 260
7
0 – 6400
0 – 5000
0 – 260
7
0 – 6400
0 – 5000
0 – 260
7
Moment of inertia of the graduated disc
Shaft height (mounting base height to mid-
dle of drive coupling)
Drive coupling
kgm
2
mm
1,5
125
non-floating
multi-plate clutch
1,5
125
non-floating
multi-plate clutch
1,5
125
non-floating
multi-plate clutch
1,5
125
non-floating
multi-plate clutch
Number of test points
Size of measuring glass
Measuring range
Flow rate depending on speed
quantity
ml
l/h
mm³/
stroke
12
44 and 260
-
-
12
-
0,03 – 30
0,2 – 3000
12
44 and 260
-
-
12
-
0,03 – 30
0,2 – 3000
*)
Nominal speed (no),
EPS807 = 850 U/min
-1
EPS815 = 580 U/min
-1
