10 Technical specifications
152 Operating Manual ARC 400 BOWA-IFU-11779-ARC400-V2.1.0-S0-EN
LIGATION / TissueSeal PLUS
Measurement at ohmic resistances
 Diagram of power output P [W] as a
function of the load resistance R [] for
the setting "LIGATION"
 Power output P [W] as a function of the
setting " LIGATION " Rated load
resistance (25 )
= 200 W
 HF output voltage U [Vp] for the setting
" LIGATION " (idle mode)
= 190 Vp
