Broadcom NetXtreme Ethernet Adapter • Diagnostic User’s Guide
page 46
Broadcom Confidential and Proprietary
ENGINEERING_CHANGE = string (10)
MANUFACTURING_ID = string (4)
ASSET_TAG = string (16)
FORCE_PCI = {enable, disable}
VOLTAGE_SOURCE = {1.3, 1.8}
LED_MODE = {mac_mode, triple_link /phy_mode1,
link_speed/phy_mode2, shared_traffic, shasta_mac, wireless_combo}
MAX_PCI_RETRY = {0..7, auto}
ASF = {enable, disable}
DUAL_MAC_MODE = {normal, mac0, mac1, xbar, swap, swapxbar} **
normal: Ch.0 and Ch. 1 enableds
macb: Ch.0 enabled, Ch.1 disabled
maca: Ch.0 disabled, Ch.1 enabled
xbar: Both MACs shares one function in PCI configuration space
swapxbar :
swap: swap between Ch.0 and Ch1.
MBA_BOOT_PROTOCOL = { pxe, rpl, bootp, iscsi}
MBA_BOOTSTRAP_TYPE = {auto, bbs, int18, int19}
MBA_DELAY_TIME = {0..15}
EXPANSION_ROM_SIZE = {64K, 128K, 256K, 512K, 1M, 2M, 4M, 8M, 16M}
DESIGN_TYPE = {nic, lom}
VENDOR_SPECIFIC0 = string (16)
VENDOR_SPECIFIC1 = string (16)
REVERSE_NWAY = {yes, no}
WOL_LIMIT_10 = {yes, no}
FIBER_WOL_CAPABLE = {yes, no}
CLOCK_RUN_SETTING = {enable, disable}
DISABLE_POWER_SAVING = {yes, no}
HIDE_MBA_SETUP_PROMPT = {enable, disable}
MBA_SETUP_HOT_KEY = {Ctrl-S, Ctrl-B}
ENABLE_AUTO_POWERDOWN = {yes, no}
CAPACITIVE_COUPLING = {enable, disable}
PRI_SMB_ADDR = {Hex(value)}
SEC_SMB_ADDR = {Hex(value)}
L1ASPM_Debounce_En = {enable, disable}
*This should only be used to select port for dual ports devices.
** This is for dual port devices only.
For Selfboot Firmware:
MAC_ADDRESS = xx:xx:xx:xx:xx:xx
SYSTEM_DEVICE_ID = xxxx
SUBSYSTEM_VENDOR_ID = xxxx
SUBSYSTEM_DEVICE_ID = xxxx
WOL = {enable, disable}
WOL_LIMIT_10 = {yes, no}
DESIGN_TYPE = {nic, lom}
ENABLE_AUTO_POWERDOWN = {yes, no}
REVERSE_NWAY = {yes, no}
DISABLE_POWER_SAVING = {yes,no}
CABLE_SENSE = {enable, disable}
LED_MODE = {mac_mode, phy_mode1, phy_mode2,
shared_traffic, shasta_mac, wireless_combo}
POWER_DISSIPATCHED _CONSUMED = d0:d1:d2:d3:d4 *
To Next Page
