Broadcom NetXtreme Ethernet Adapter • Diagnostic User’s Guide
page 69
Broadcom Confidential and Proprietary
Disable (0) Disable TX driver per-emphasis.
Enable (1) Enable TX driver per-emphasis.
45
Reserved. Option no longer in use. Reference
46
Encoded Hot Plug Power 1 & 2 For NIC
Configure
Description:
Encoded Hot plug power values 1 & 2 for a NIC device that is used only if enabled in
option 50 below. The following description applies to options 46-49.
This option is only valid for 5787 and 575xCx devices. The power values need to be setup
by the OEM / manufacture based on actual measurements. Default values, contained in
the bootcode / firmware, are loosely based on the in house Broadcom NIC card.
15-0 Power Budget data 1
7-0 Base Power in .1 Watt
For example, 1.4 Watt should have value 14.
9-8 PM State
00 D0
01 D1
10 D2
11 D3
12-10 Type
000 PME Aux
001 Auxiliary
010 Idle
011 Sustained
111 Maximum
13-15 Power Rail
000 12V
001 3.3V
010 1.8V
111 Thermal
31-16 Power Budget data 2
See Power Budget Data 1 for detail, Bit number add 16.
47
Encoded Hot Plug Power 3 & 4 For NIC
Configure
Description:
Encoded Hot plug power values 3 & 4 for a NIC device that is used only if enabled in
option 50 below. Look at option 46 for details.
48
Encoded Hot Plug Power 5 & 6 For NIC
Configure
Description:
Encoded Hot plug power values 5 & 6 for a NIC device that is used only if enabled in
option 50 below. Look at option 46 for details.
49
Encoded Hot Plug Power 7 & 8 For NIC
Configure
