Brother DCP-L5652DN Service Manual

2-19
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
9105 ― 9502 ―
9200 ― 9503 ―
9201
When printing from the MP tray, paper
type setting in the machine does not
match the setting in the driver.
2-68 9504 ―
9202
When printing from the paper tray 1,
paper type setting in the machine
does not match the setting in the
driver.
2-68
9505 ―
9203
When printing from the paper tray 2,
paper type setting in the machine
does not match the setting in the
driver.
2-68
9601 ―
9204
When printing from the paper tray 3,
paper type setting in the machine
does not match the setting in the
driver.
2-68
9608 ―
9205
When printing from the paper tray 4,
paper type setting in the machine
does not match the setting in the
driver.
2-68 9701
A tray set to duplex printing-
incompatible size was specified in
duplex printing.
2-72
9206
When printing from the paper tray 5,
paper type setting in the machine
does not match the setting in the
driver.
2-68 9702
When printing from paper tray 1, a
paper size not supported for paper
tray 1 was specified from the driver.
2-72
9301
When printing from the MP tray, the
MP paper empty sensor detected that
there was no paper set in the MP tray.
2-69 9703
When printing from paper tray 2, a
paper size not supported for paper
tray 2 was specified from the driver.
2-72
9302
When printing from paper tray 1, the
T1 paper empty sensor or the T1
paper feed sensor detected that there
was no paper set in paper tray 1.
2-69 9704
When printing from paper tray 3, a
paper size not supported for paper
tray 3 was specified from the driver.
2-72
9303
When printing from paper tray 2, the
T2(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 2.
2-69 9705
When printing from paper tray 4, a
paper size not supported for paper
tray 4 was specified from the driver.
2-72
9304
When printing from paper tray 3, the
T3(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 3.
2-69 9706
When printing from paper tray 5, a
paper size not supported for paper
tray 5 was specified from the driver.
2-72
9305
When printing from paper tray 4, the
T4(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 4.
2-69
9801 ―
9306
When printing from paper tray 5, the
T5TT paper empty sensor detected
that there was no paper set in paper
tray 5.
2-69
9802 ―
9309
Detected that there was no paper set
in all trays when TrayAuto was
selected for printing.
2-70 9803 ―
930A
Paper ran out during Fax / List
continuous printing.
2-71
9804 ―
9400
Firmware version of the main PCB is
older than that of the TT and LT.
2-71
9901 ―
9501 ― 9902 ―

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
