Brother DCP-L5652DN Service Manual

2-32
Confidential
Size Mismatch Reload correct paper. Detected that the size of paper set
in the paper tray was over 10 mm
shorter than letter size during
receiving fax data or printing a list
or report.
8E02 2-66
Reload correct paper
in MP Tray, then press
[Retry].
When printing from the MP tray,
the size of paper set in the MP tray
does not match the size specified
by the driver.
9001 2-67
Reload correct paper
in Tray1, then press
[Retry].
When printing from the paper tray
1, the size of paper set in the
paper tray 1 does not match the
size specified by the driver.
9002 2-67
Reload correct paper
in Tray2, then press
[Retry].
When printing from the paper tray
2, the size of paper set in the
paper tray 2 does not match the
size specified by the driver.
9003 2-67
Reload correct paper
in Tray3, then press
[Retry].
When printing from the paper tray
3, the size of paper set in the
paper tray 3 does not match the
size specified by the driver.
9004 2-67
Reload correct paper
in Tray4, then press
[Retry].
When printing from the paper tray
4, the size of paper set in the
paper tray 4 does not match the
size specified by the driver.
9005 2-67
Reload correct paper
in Tray5, then press
[Retry].
When printing from the paper tray
5, the size of paper set in the
paper tray 5 does not match the
size specified by the driver.
9006 2-67
Supplies Toner Low Dot counter or develop roller
counter of the toner is reaching
the upper limit.
4B01 2-45
Drum End Soon. The number of rotations of the
drum unit is reaching the upper
limit.
4000 2-44
Replace Drum The number of rotations of the
drum unit has reached the upper
limit. (Printing does not stop.)
4200 2-44
Too Many Trays Turn the power off and
remove additional
trays.
Detected more LTs than
connectible limit. 6D00 2-50
Touchscreen
initialization failed
Remove any material
which is on the
touchscreen.
An error occurred while initializing
the touch panel. D800 2-79
Unable to
Update:**
Check the firmware
update file and try
again.
Cannot execute USB Memory
Firm UPDATE. --- 4.14.2
Error message
Description
Error
codes
Refer
to:
First line Second line

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
