* The parenthesis shows the LCD model.
MP PE sensor ASSY Taptite bind B M3x8 1 0.5±0.1 (5±1)
MP frame Taptite bind B M4x12 2 0.7±0.1 (7±1)
PE EG sensor ASSY Taptite bind B M3x8 1 0.5±0.1 (5±1)
LT front cover Taptite bind B M4x12 2
LT rear cover Taptite cup S M3x6 SR 2
LT side cover L
Taptite bind B M4x12 1
Taptite cup S M3x6 SR 1
LT side cover R
Taptite bind B M4x12 1
Taptite cup S M3x6 SR 1
LT PCB ASSY Taptite bind B M4x12 1
Feed roller ground plate Taptite cup S M3x6 SR 1
LT drive uint Taptite bind B M4x12 4
LT solenoid ASSY Taptite bind B M3x10 1
LT frame L
Taptite bind B M4x12 2
Taptite cup S M3x6 SR 4
LT frame R Taptite cup S M3x6 SR 2
LT front beam Taptite cup B M3x12 2
LT sensor PCB ASSY Taptite bind B M3x8 1
Location of screw Screw type Q’ty
Tightening torque
N m (kgf · cm)
To Next Page
