1-2
Confidential
2. SPECIFICATIONS LIST
2.1 Printing
*1
Using 1200 dpi setting (1200 x 1200 dpi) the print speed will be slower.
*2
The time may change if the machine is calibrating or registering itself.
Specifications are subject to change without notice.
Model HL-5340D
HL-5350DN
HL-5350DNLT
HL-5370DW
HL-5370DWT
HL-5380DN
Print method Electrophotography by semiconductor laser beam
scanning
Laser Method: 1 polygon motor, 1 laser beam
Wavelength: 770 nm - 810 nm
Output: 5 mW (Max)
Laser class: Class3 B
Resolution
1200 dpi
*1
,
HQ1200
(2400x600dpi)
Windows
®
2000/XP/ XP Professional x64 Edition, Windows
Vista
®
, Windows Server
®
2003/ Windows Server
®
2003 x
64 Edition, Windows Server
®
2008, Mac OS
®
X 10.3.9 or
greater, Linux
600 x 600 dpi
Windows
®
2000/XP/ XP Professional x64 Edition, Windows
Vista
®
, Windows Server
®
2003/ Windows Server
®
2003 x
64 Edition/ Windows Server
®
2008, Mac OS
®
X 10.3.9 or
greater, DOS, Linux
Print mode Normal printing mode
Economy printing mode (Toner saving mode)
Print Speed
(A4/Letter)
Standard Up to 30/32 ppm
* When loading A4 or Letter-size paper from the
standard paper tray.
Duplex A4: Up to 13 sides per minute (6.5 sheets per minute)
Letter: Up to 14 sides per minute (7 sheets per minute)
Warm-up time
*2
From sleep mode: less than 18 seconds
From power off
on: less than 28 seconds
First print time
*2
Less than 8.5 seconds
Consumables Toner cartridge Life expectancy:
Standard: 3,000 pages/cartridge
High-capacity: 8,000 pages/cartridge
* When printing A4/Letter-size paper in accordance with
ISO/IEC 19752.
Shelf life: 2 years without opening (6 months after
opening)
Drum unit Life expectancy: 25,000 pages/drum unit
Life expectancy will vary depending on number of
continuous printing pages. (Refer to CHAPTER 7 1.3
Service Mode "Printing for Maintenance".)
* When printing A4/Letter-size paper.
Shelf life: 2 years without opening (6 months after
opening)
The shelf life mentioned above is guaranteed under the normal condition as
below;
(Temperature) Normal condition: 0 to 40 °C
* Storage condition at the temperature of 40 to 50 °C: Up to 5 days
* Storage condition at the temperature of -20 to 0 °C: Up to 5 days
(Humidity) Normal condition: 35 to 85 %
* Storage condition at the humidity of 85 to 95 %: Up to 5 days
* Storage condition at the humidity of 10 to 35 %: Up to 5 days
