Brother HL-5350DN Service Manual

3-15
Confidential
2.2.2 Error indication at Service Calls
If LED indication does not operate when service calls occur, you can use a maintenance tool
to distinguish the type of error.
SIZE MISMATCH
Mismatch between specified paper size from the
driver and setting paper in the tray.
3-24
STORAGE FULL Memory full. 3-24
TOO MANY TRAYS Option tray is installed more than three. 3-24
REPLACE TONER Toner life end is detected. Developer count full. 3-25
TONER LOW Low on toner. 3-25
Error indication
(Printing of Printer Settings)
Error indication
(Printing of Maintenance)
Type of error
Refer
to:
ERROR S01 ERROR S01 ■ MAIN PCB FAILURE
3-25
ERROR S02 ERROR S02
ERROR S03 ERROR S03
ERROR S04 ERROR S04
ERROR S05 ERROR S05
ERROR S06 ERROR S06
ERROR S07 ERROR S07
ERROR S08 ERROR S08
ERROR S09 ERROR S09
ERROR S10 ERROR S10
ERROR S11 ERROR S11
ERROR S12 ERROR S12
ERROR S13 ERROR S13
ERROR E49 FUSER MALF 2 ■ FUSER UNITFAILURE
3-26ERROR E50 FUSER MALF
ERROR FUSER ERROR FUSER
ERROR E51 LASER BD MALF
■ LASER UNIT FAILURE
(Laser beam detection error)
3-26
ERROR E52 SCANNER MALF
■ LASER UNIT FAILURE
(Scanner motor failure)
3-26
ERROR E54 MOTOR MALF ■ MAIN MOTOR FAILURE 3-26
ERROR E55 HIGH VOL MALF
■ HIGH-VOLTAGE POWER
SUPPLY PCB FAILURE
3-27
ERROR E60 ERROR E60 ■ FAN FAILURE 3-27
ERROR H61 PROG ERROR ■ MAIN PCB FAILURE
3-25
ERROR H63 ERROR H63
ERROR H66 NV-W ERROR
ERROR H67 NV-R ERROR
ERROR H68 NV-B ERROR

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
