Brother HL-5350DN Service Manual

5-3
Confidential
3. SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening torque
N m (kgf · cm)
FU harness cover 1 Taptite pan B M4x20 1 0.7±0.1 (7±1)
Fuser unit Taptite pan B M4x20 1 0.7±0.1 (7±1)
Process cover stopper Taptite cup B M4x10 1 0.5±0.1 (5±1)
Emblem cover Taptite bind B M3x10 2
0.5 ± 0.1 (5 ± 1)
Side cover L Taptite bind B M4x12 2 0.7±0.1 (7±1)
Shield cover Taptite cup S M3x6 SR 4 0.75±0.1 (7.5±1)
Main PCB
Taptite cup S M3x6 SR 4 0.75±0.1 (7.5±1)
Set screw 2 0.5±0.1 (5±1)
Side cover R Taptite bind B M4x12 2 0.7±0.1 (7±1)
Top cover printed ASSY Taptite bind B M4x12 2 0.7±0.1 (7±1)
Panel PCB ASSY Taptite cup B M3x8 3 0.5±0.05 (5±0.5)
Inner chute Taptite bind B M4x12 6(7) 0.8±0.1 (8±1)
Gear plate calking ASSY
Taptite bind B M4x12 8 0.9±0.05 (9±0.5)
Taptite cup S M3x6 SR 1 0.7±0.1 (7±1)
Main motor ASSY Taptite cup S M3x6 4 0.7±0.1 (7±1)
Plate Taptite bind B M4x12 2 0.8±0.1 (8±1)
Main shield plate ASSY
Taptite bind B M4x12 3 0.9±0.1 (9±1)
Taptite cup S M3x6 1 0.7±0.1 (7±1)
MP solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Spring Taptite cup B M3x8 1 0.4±0.1 (4±1)
T1 solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Register solenoid ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Ejector solenoid ASSY Taptite bind B M3x10 1
0.5 ± 0.1 (5 ± 1)
New toner actuator Taptite cup B M2x6 1
0.13±0.03
(1.3±0.3)
Laser unit Taptite cup S M3x6 5 0.7±0.1 (7±1)
Base plate LV
Taptite bind B M4x12 5 0.8±0.1 (8±1)
Screw, pan (S/P washer)
M3.5X7.5 SR
10.4±0.05 (4±0.5)
LV insulation sheet Taptite bind B M4x12 1 0.8±0.1 (8±1)
SW holder ASSY Taptite bind B M4x12 1 1.0±0.1 (10±1)
Safety louver Taptite bind B M3x10 1 0.5±0.1 (5±1)
Base plate HV Taptite bind B M4x12 4 0.8±0.1 (8±1)
HV insulation sheet Taptite bind B M4x12 1 0.8±0.1 (8±1)
High-voltage PS PCB ASSY Taptite bind B M4x12 1 0.8±0.1 (8±1)
Toner LED PCB unit ASSY
Taptite pan (washer) B
M3x8
10.5±0.1 (5±1)
Frame L Taptite bind B M4x12 6 0.8±0.1 (8±1)
MP feed frame Taptite bind B M3x8 2 0.5±0.1 (5±1)

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
