Brother HL-5350DN Service Manual

7-5
Confidential
1.3 Service Mode
The service mode is exclusively designed for the purpose of checks, settings and
adjustments, and this function should be accessed by service personnel only. You can
perform a print test and display the log information.
<Procedure>
<LED model>
(1) Check that the front cover is open.
(2) Turn ON the power switch while the [Go] button is held.
(3) After all LEDs on the panel are lit, only the Status LED goes out.
(4) Release the [Go] button and check that all LEDs are out.
(5) Press the [Go] button once or twice. (If the [Go] button is pressed, the Status LED is lit.
If the [Go] button is released, the LED is out.)
(6) Check that Toner/Drum/Paper LEDs are lighted.
(7) Press the [Go] button depending on the necessary number of times. Each mode starts
after 2 seconds. (If the [Go] button is pressed, the Status LED is lit. If the [Go] button is
released, the LED is out.)
<LCD model>
(1) Check that the front cover is open.
(2) Turn ON the power switch while the [Go] button is held.
(3) The message “USERS MODE” is shown on the LCD panel.
(4) Release the [Go] button and check that the Data LED is out. (Backlight is green.)
(5) Press the [Go] button once or twice. (If the [Go] button is pressed, the Data LED is lit. If
the [Go] button is released, the LED is out.)
(6) Check that the message “USERS MODE” is shown on the LCD panel with orange backlight.
(7) Press the [Go] button depending on the necessary number of times. Each mode starts
after 2 seconds. (If the [Go] button is pressed, the Data LED is lit. If the [Go] button is
released, the LED is out.
Press the [Go] button once.
Press the [Go] button again depending on the necessary number of times after check
that Toner/Drum/Paper LEDs are lighted.
Press the [Go] button Mode
Once 9) Factory Inspection Mode
Twice 10) Continuous Grid Pattern Print Mode
Three times 11) Fixing Unit Test Print
Four times 12) NV-RAM Value Dump Mode
Five times 13) RAM Check
Six times 14) QA Test print
Seven times 15) DX setting (ON/OFF)
Eight times 16) Paper Size Setting (A4/Letter)
Nine times 8) PCB ONLY Mode
More than Ten times Go back to Normal State

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
