2.2 Error Message (LCD model)
2.2.1 Operator calls
An "Operator call" which the printer indicates on the LCD display is user recoverable.
Identify the error from the table below and take the corrective action described for each
indication to correct it. The printer automatically recovers from most errors. If not, the error
is cleared by holding down the [Go] button on the control panel.
The LCD names for the paper trays are as follows.
• Upper paper tray: TRAY 1
• Multi-purpose tray: MP
• Optional Lower tray: TRAY 2 or TRAY 3
■ Error message
Error message Type of error
Refer
to:
BUFFER ERROR Mistake the Interface settings. 3-16
CARTRIDGE ERROR
A new one cannot be detected for the operation
failure of new toner actuator.
3-16
DIMM ERROR
The failed DIMM is installed, or the DIMM is not
installed correctly.
3-16
DOWNLOAD FULL Memory full. 3-16
DRUM END SOON
The drum unit reached 90% of the time for
replacement.
3-17
DRUM ERROR Dirt on drum unit. (Dirt on the corona wire) 3-17
DUPLEX DISABLED The back cover is open, or the DX unit is not set. 3-19
FONT FULL
The number of the registration of the font is
overflowed.
3-19
FRONT COVER OPEN Front cover is opened. 3-19
FUSER COVER OPEN Fuser cover is opened. 3-20
JAM XXX No paper in Tray 1 (T1)/2 (T2)/3 (T3). 3-20
MANUAL FEED No paper in MP tray. 3-21
MEMORY FULL Memory full. 3-22
NO PAPER XXX No paper in specified tray, or specified tray is not set. 3-22
NO TONER No toner cartridge is detected. 3-22
NO TRAY XX
If feed from the T2/T3, the T1/T2 in the paper path is
not installed.
3-23
PRINT OVERRUN
Print date capacity is flooded the memory capacity of
machine.
3-23
REPLACE DRUM
Drum unit is the time for replacement. Replace the
drum unit.
3-23
REPLACE FUSER Fuser unit is the time for replacement. 3-23
REPLACE LASER Laser unit is the time for replacement. 3-23
REPLACE PF KIT 1
(2, 3, MP)
PF kit 1 (2, 3, MP) is the time for replacement.
3-24
SIZE ERROR DX
Specified paper size is not supported for duplex
printing.
3-24
