Brother HL-5350DN Service Manual

7-16
Confidential
2. HIDDEN FUNCTION MENUS
The three hidden function menus are provided for the HL-5380DN printer with the LCD.
(1) Professional Menu: by pressing the [Go] and [Set] buttons at the same time.
Refer to "2.1 Professional Menu" in this chapter
(2) Reset Parts Life Menu: by pressing the [Go] and [+] buttons at the same time.
Refer to "2.2 Reset Parts Life Menu" in this chapter
(3) Service Menu: by pressing the [+] and [Set] buttons in this order while holding down the
[Go] button.
Refer to "2.3 Service Menu" in this chapter
The method to enter the special mode by the button operation is as follows:
<Pressing the 1 button when the printer is turned ON>
<Pressing the 2 button when the printer is turned ON>
<Pressing the 2 button in the normal status>
<Others in the normal status>
Panel Function
Go To Users Mode
Secure Print Continuous test printing
+ Version Check
- Hex Dump Mode
Set Initializing the NVRAM
Panel Function
Set & Back Rewriting the Flash ROM
Go & + Checking the hardware (DRAM check, etc.)
- & + Factory Line Inspection Mode
- & Set High-voltage power supply Check Mode
Go & Set Clearing the E50 (FUSERMULF)
Panel Function
Go & + RESET PARTS LIFE (Clearing the counters of the periodical
replacement parts)
Go & Set Professional Menu
- & Set Indicating the error descriptions (The details of the service call or paper
jam occurrence section are indicated in English.)
Panel Function
Go & (+, Set) Service Menu (Acquiring the service information such as the number of
replacement or paper jam occurrence, error, etc.)

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
