Brother HL-5350DN Service Manual

1-7
Confidential
<Wireless network>
Network node type NC-7600w
Operating system
support
Windows Vista
®
, Windows Server
®
2003 x64 Edition
*2
, Windows
®
XP
Professional x64 Edition
*1
, Windows
®
2003, Windows
®
XP, Windows
®
2000, Mac OS
®
X 10.3.9 or greater
Protocol support TCP/IP: IPv4 ARP, RARP, BOOTP, DHCP, APIPA (Auto IP),
WINS/ NetBIOS name resolution, DNS Resolver,
mDNS, LLMNR responder, LPR/LPD, Custom Raw
Port/Port9100, IPP/IPPS, FTP Server, TELNET
Server, HTTP/HTTPS server, TFTP client and
server, SMTP Client, APOP, POP before SMTP,
SMTP-AUTH, SNMP v1/v2c/v3, ICMP, LLTD
responder, Web Services Print
TCP/IP: IPv6
*2
NDP, RA, DNS resolver, mDNS, LLMNR responder,
LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS,
FTP Server, TELNET Server, HTTP/HTTPS server,
TFTP client and server, SMTP Client, APOP, POP
before SMTP, SMTP-AUTH, SNMPv1/v2c/v3,
ICMPv6, LLTD responder, Web Services Print
Network type IEEE 802.11b/g wireless
Frequency 2412 - 2472 MHz
RF channel US/Canada 1 - 11
Europe/Oceania 1 - 13
Japan 1 - 14
Communication
mode
Infrastructure, Ad-hoc 802.11 b
Data rate 802.11 b 11/5.5/2/1 Mbps
802.11 g 54/48/36/24/18/12/11/9/6 Mbps
*1
A wireless network connection is supported only between the Brother printer and an
access point for PC's running Windows Server
®
2003 x64 Edition and Windows
®
XP
Professional x64 Edition.
*2
If you want to use the IPv6 protocol, visit http://solutions.brother.com for more information.
Link distance 70 m (233 ft.) at lowest data rate (The distance rate will vary upon
environment and other equipment location.)
Network security WEP 64/128, WPA-PSK (TKIP), WPA2-PSK (TKIP & AES), LEAP,
EAP-FAST
Management utility BRAdmin Professional 3
*2
for Windows
(Brother original Windows utility for printer and server management)
Web BRAdmin
*2
for Windows
(Server based management utility / Windows IIs (4.0/5.0) mode only)
Web Based Management
BRAdmin Light for Windows and Macintosh
(Printer and print server management throuth web browser)
recommend Microsoft Internet Explorer 6.0 (or greater), Fire fox 1.0 (or
greater) for Windows
Safar: 1.2 (or greater) for Macintosh
*3
BRAdmin Professional 3 and Web BRAdmin are available as a download from
http://solutions.brother.com
.

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
