Brother HL-5350DN Service Manual

1-5
Confidential
2.3 Electronics and Mechanics
Model
HL-
5340D
HL-
5350DN
HL-
5350DNLT
HL-
5370DW
HL-
5370DWT
HL-
5380DN
Power
consumption
Printing Average510 W at 25 °C (77 °F)
Standby Average 85 W at 25 °C (77 °F)
Sleep
Average 8
W at 25 °C
(77 °F)
Average 9 W at 25 °C (77 °F) Average
12 W at 25
°C (77 °F)
Noise level Sound
Pressure
Printing: 54 dB (A)
Standby: 35 dB (A)
Sound
power
Printing: LWAd = 7.0 Bell (A)
Standby: LWAd = 4.6 Bell (A)
Temperature Operating: 10 to 32.5°C (50 to 90.5 °F)
Non operating: 0 to 40°C (38 to 104 °F)
Storage: -20 to 40°C (-4 to 104 °F)
Humidity Operating: 20 to 80 % (non condensing)
Storage: 10 to 85 % (non condensing)
Dimensions of the main
body (WxDxH)
371x384x246mm
(14.6x15.1x9.7in.)
371x384x
347mm
(14.6x15.
1x13.7in.)
371x384x
246mm
(14.6x15.
1x9.7in.)
371x384x
347mm
(14.6x15.
1x13.7in.)
393x384x
259mm
(15.5x15.
1x10.2in.)
Weight the main
body with
Carton
11.7kg
(25.8lb)
19.5kg
(42.9lb)
11.7kg
(25.8lb)
19.5kg
(42.9lb)
11.9kg
(26.2lb)
the main
body
without
Carton
9.5kg
(20.9lb)
12.2kg
(26.9lb)
9.5kg
(20.9lb)
12.2kg
(26.9lb)
9.5kg
(20.9lb)

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
