Brother HL-5350DN Service Manual

2-12
Confidential
3.3.2 Cartridge life
A new toner cartridge can print approximately 3,000 (standard toner) or approximately 8,000
(high yield toner) A4 or Letter size single-sided pages at normal duty (ISO/IEC19752). In the
case of low-duty printing, if the number of printed pages are reached the cartridge life,
"Replace Toner" is indicated by lighting Toner LED (HL-5340D/5350DN/5350DNLT/
5370DW/5370DWT) or "Replace Toner" message appears on the LCD panel (HL-5380DN)
before the toner runs out because the developer roller surface or other toner sealing is worn
out due to a rotation of the rollers.
<Cartridge Life>
As the deterioration of toner will be less in case of printing more pages continually once time
than usual, the more printing pages per job, the more printable pages of toner cartridge.
Increasing the number of times of power switch ON and warming operation in company with
opening or closing cover will also cause the deterioration of toner, so the more frequency
those operations be taken, the less pages the toner cartridge can print.
Memo :
• If reached the cartridge life end, "Replace Toner" message appears even if the
toner is contained.
Table: The relationship between the average printing pages per job and the toner cartridge life
Average printed pages
(page/job)
12345678
Cartridge Life (Standard) 3,500 5,274 6,346 7,064 7,579 7,966 8,267 8,508
Cartridge Life (High Yield) 9,500
14,315 17,225 19,174 20,571 21,621 22,439 23,094
Table: The toner cartridge lives in case of pressing power switch Off/ON before printing.
Average printed pages
(page/job)
12345678
Cartridge Life (Standard) 1,925 3,263 4,246 5,000 5,596 6,079 6,478 6,814
Cartridge Life (High Yield) 5,225 8,856
11,526 13,571 15,189 16,500 17,584 18,496
Toner life
Full
Low
Empty
pages
Cartridge Life End
Toner EmptyToner Empty
Low-duty
High-duty
Normal-duty
(ISO/IEC19752)

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
