2.2 Functions
<Controller>
<Software>
Download from http://solutions.brother.com.
Model HL-5340D
HL-5350DN
HL-5350DNLT
HL-5370DW
HL-5370DWT
HL-5380DN
CPU 300 MHz
Memory Standard
16 MB 32 MB
Option
1 DIMM slot;
expandable
up to 528 MB
1 DIMM slot; expandable up to 544 MB
Interface IEEE 1284
Parallel, Hi-
Speed USB
2.0
IEEE 1284
Parallel, Hi-
Speed USB
2.0, Ethernet
10/100
BASE-TX
IEEE 1284
Parallel, Hi-
Speed USB
2.0, Ethernet
10/100
BASE-TX,
Wireless
LAN IEEE
802.11b/g
IEEE 1284
Parallel, Hi-
Speed USB
2.0, Ethernet
10/100
BASE-TX
Emulation
PCL6, BR-Script 3 (PostScript
®
3™), IBM Proprinter XL,
Epson FX-850
Network
Connectivity
Protocol N/A TCP/IP(10/100 BASE-TX Ethernet)
Management tool N/A BRAdmin Light, Web BRAdmin, Web
Based Management , BRAdmin
Professional 3
Resident fonts PCL 66 scalable fonts, 12 bitmap fonts, 13 bar codes
BR-Script 3 66 scalable fonts
Model HL-5340D
HL-5350DN
HL-5350DNLT
HL-5370DW
HL-5370DWT
HL-5380DN
Printer driver Windows
®
PCL driver for Windows 2000 Professional, XP Home
Edition, XP Professional Edition, XP professional x64
Edition, Server 2003, Server 2003 x64 Edition, Vista,
Server 2008
BR-Script 3 (PPD file for Windows 2000 Professional, XP
Home Edition, XP Professional Edition, XP professional
x64 Edition, Server 2003, Server 2003 x64 Edition, Vista,
Server 2008)
Macintosh
®
Macintosh Printer Driver for Mac OS
®
X 10.3.9 or greater
BR-Script 3 (PPD file for Mac OS
®
X 10.3.9 or greater)
Linux * Linux printer driver for CUPS printing system (x86, x64
environment)
Linux printer driver for LPD/LPRng printing system (x86,
x64 environment)
Utility N/A Driver Deployment Wizard

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
