Brother HL-5350DN Service Manual

3-19
Confidential
■ DUPLEX DISABLED
The back cover is open, or the DX unit is not set.
■ FONT FULL
The number of the registration of the font is overflowed.
■ FRONT COVER OPEN
Front cover is opened.
<User Check>
- Close the back cover.
- Set the DX unit.
Step Cause Remedy
1
Harness connection failure of back
cover sensor
Check the sensor performance following
the procedure in "Factory Inspection Mode"
in 1.3 Service Mode in Chapter 7.
If any problem occurs, check the harness
connection of the back cover sensor, then
reconnect it.
2 Broken boss of back cover Replace the back cover.
3 Back cover sensor failure Replace the back cover sensor.
4 Main PCB ASSY failure Replace the main PCB ASSY.
<User Check>
- Cut down the registration of the font.
- Add on the DIMM.
Step Cause Remedy
1 Main PCB ASSY failure Replace the main PCB ASSY.
<User Check>
- Check if the front cover is closed certainly.
Step Cause Remedy
1
Harness connection failure of
interlock SW ASSY
Check the harness connection of the
interlock SW ASSY, and reconnect it.
2
Interlock SW ASSY failure Check the sensor performance following
the procedure in "Factory Inspection Mode"
in 1.3 Service Mode in Chapter 7.
If any problem occurs, check the harness
connection of the interlock SW ASSY, then
reconnect it.
3
Part pressing the cover sensor
harness ASSY is broken, which is
provided at inside of process cover
Replace the process cover ASSY.
4 Relay front PCB ASSY failure Replace the relay front PCB ASSY.
5 Main PCB ASSY failure Replace the main PCB ASSY.

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
