Brother MFC-J2320 Service Manual

5-75
Confidential
• Selectors 6 through 8: Adjustment of print head drive voltage rank
This selector regulates the print head drive voltage rank for adjusting the ink drop
amount.
If the black section printed on glossy paper is greenish or the printed ink does not
dry quickly, increase the print head drive voltage rank to decrease the ink drop
amount; if it is reddish, decrease the rank to increase the ink drop amount.
AMS06 (Printing assurance 4)
• Selectors 1 and 2: Improvement of white and black horizontal streaks on bottom edge of the
paper during normal and high-speed printing on plain paper
Setting these selectors enables improvement of the white and black horizontal streaks
on the bottom edge of paper during normal and high-speed printing on plain paper.
• Selectors 3 and 4: Improvement of white and black horizontal streaks from leading edge to
center of paper during high-speed and normal print on plain paper
Setting these selectors enables improvement of the white and black horizontal streaks
from the leading edge to the center of paper during normal and high-speed printing on
plain paper.
• Selectors 5 and 6: Improvement of white and black horizontal streaks during print on glossy paper
Setting these selectors enables improvement of the white and black horizontal
streaks during printing on glossy paper.
Selector
No.
Function Setting and Specifications
1
2
Improvement of white and black
horizontal streaks on bottom
edge of the paper during normal
and high-speed printing on plain
paper
No. 1 2
0 0 : Disable (default)
0 1 : Improve black horizontal streaks
1 0 : Improve white horizontal streaks
1 1 : Further improve black horizontal
streaks
3
4
Improvement of white and black
horizontal streaks from leading
edge to center of paper during
high-speed and normal print on
plain paper
No. 3 4
0 0 : Disable (default)
0 1 : Improve black horizontal streaks
1 0 : Improve white horizontal streaks
1 1 : Further improve black horizontal
streaks
5
6
Improvement of white and black
horizontal streaks during print on
glossy paper
No. 5 6
0 0 : Disable (default)
0 1 : Improve black horizontal streaks
1 0 : Improve white horizontal streaks
1 1 : Further improve black horizontal
streaks
7
Extension of the lower range of
printable temperatures
0: Disable (default) 1: Enable
8 Not used.
