Separating the DADF Unit + Reader Unit
■ Preparation
1. “Removing the Cartridge” on page 77
2. “ Removing the Left Cover” on page 80
3. “Removing the DADF Unit + Reader Unit” on page 93
■ Procedure
CAUTION:
Do not damage the White Sheet and White Guide Plate.
1.
NOTE:
Be sure to put a piece of paper and place the Control Panel Unit on it carefully so as not to damage it.
4. Parts Replacement and Cleaning
96
To Next Page
