When the door open is detected, the Engine Controller PCB (UNIT1) stops drive of the motors and solenoids.
Fan Control
This machine uses a fan to prevent temperature rise inside the machine.
Sym-
bol
Name Cooling area Type Speed Failure
Detection
FM1 Main Fan Inside the printer Suction Full
speed
Yes
Error Code
E806: Main Fan failure
• E806-0000: The Main Fan Motor fails to rotate at the specified rotation speed.
2. Technology
35
