COPIER (Service mode for printer) > DISPLAY (State display mode)
COPIER (Service mode for printer) > DISPLAY (State display mode) > CCD
DF-TARGET-BW Display shading target value (B&W): ADF
Detail To display the shading target value of B&W at ADF stream reading.
Use Case
At scanned image failure
Adj/Set/Operate Method
N/A (Display only)
Display/Adj/Set Range
128 to 384
Related Service Mode
COPIER > ADJUST > CCD > DFTAR-BW
Supplement/Memo
ADF model only
I/O (I/O display mode)
■ R-CON
COPIER (Service mode for printer) > I/O (I/O display mode) > R-CON
P001 Display P001 port: Main Controller PCB
Detail To display P001 port of the Main Controller PCB.
DADF
- bit0: Display the DADF Document End Sensor (DES) status (PS6)
- bit1: Display the DADF Document Sensor (DS) status (PS7)
SADF
- bit0: Display the SADF Document End Sensor(DES) status (PS8)
- bit1: SADF Document Sensor (DS) status (PS9)
Display/Adj/Set Range
0/1
0: Paper absent
1: Paper present
ADJUST (Adjustment mode)
■ ADJ-XY
COPIER (Service mode for printer) > ADJUST (Adjustment mode) > ADJ-XY
ADJ-X Adjust the reading start position
Detail Decrease the setting value when non-image width is larger than the standard value.
Increase the setting value when area outside the original is copied.
As the setting value is incremented by 1, the image reading start position moves toward the trailing
edge by 0.1 mm.
Use Case
When the reading position of vertical scanning direction at copyboard reading is incorrect
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
-30 to 30
Unit
0.1 mm
Default Value
0
STRD-POS Adjust the reading position: ADF
Detail As the setting value is incremented by 1, the image reading start position moves toward the leading
edge by 0.1mm.
Use Case
When the reading position of vertical scanning direction at ADF stream reading is incorrect
Adj/Set/Operate Method
Enter the setting value, and then press OK or Apply key.
Display/Adj/Set Range
-30 to 30
Unit
0.1 mm
Default Value
0
