Pickup Feed System
Functional Configuration
The pickup, feed, and delivery systems are controlled by the DC Controller.
DC controller controls blocks of the pickup, feed, and delivery system to pickup, feed and deliver paper.
The pickup, feed, and delivery systems consist of the following three blocks.
• Pickup and feed blocks: From the pickup slot to the Fixing Unit
• Fixing and delivery blocks: From the delivery slot to the TOP Sensor.
• Duplexing blocks: from the delivery slot to the TOP Sensor
Paper flow（simplex）
Paper flow（duplex）
Pickup/Feed block
Fixing block/Delivery
Duplex block
