5. “Removing the SADF Upper Cover Unit” on page 131
6. “Removing the SADF Pickup Roller Unit” on page 137
■ Procedure
CAUTION:
Do not touch the surface of the roller with bare hands, as doing so will attach skin oil on it and decrease feedability.
1.
2.
Removing the SADF Separation Roller
■ Preparation
1. “Removing the Cartridge” on page 77
2. “ Removing the Left Cover” on page 80
3. “Removing the SADF Unit + Reader Unit” on page 126
4. “Separating the SADF Unit + Reader Unit” on page 129
5. “Removing the SADF Upper Cover Unit” on page 131
6. “Removing the SADF Pickup Roller Unit” on page 137
4. Parts Replacement and Cleaning
141
To Next Page
