Canon imageCLASS MF264dw - Electrical Components List

■ Host Machine
[1]
[8]
[6]
[4]
[5]
[9]
[10]
[2]
[3]
[7]
No. Name
[1] Fixing Film Unit
[2] Transfer Roller
[3] Duplex Frame Unit
[4] Fixing Unit
[5] Transfer Unit
[6] Duplex Reverse Unit
[7] Pickup Roller
[8] Laser Scanner Unit
[9] Low-Voltage Power Supply Unit
[10] Separation Pad Unit
Electrical Components List
■ DADF Unit + Reader Unit
SL4
M4
M3
PS6
PS7
UNIT13
4. Parts Replacement and Cleaning
71
