TESTMODE (Service mode for test print, operation check, etc.) > SCAN (SCAN Test Mode)
TESTMODE (Service mode for test print, operation check, etc.) > SCAN (SCAN Test Mode) > BOOKFEED
STOP Finish document scan operation test
Detail To finish document scanning operation test.
Adj/Set/Operate Method
Scanning operation is finished by pressing Stop.
Related Service Mode
TESTMODE > SCAN > BOOKFEED > PAGE
TESTMODE > SCAN > BOOKFEED > SPEED
TESTMODE > SCAN > BOOKFEED > START
FAX (FAX test mode)
■ MODEM
TESTMODE (Service mode for test print, operation check, etc.) > FAX (FAX test mode) > MODEM
FREQ Send selected frequency
Detail To close DC circuit and send the selected frequency using tone sending function of modem.
Adj/Set/Operate Method
Select the setting value
Display/Adj/Set Range
462Hz, 1100Hz, 1300Hz, 1500Hz, 1650Hz, 1850Hz, 2100Hz
Supplement/Memo
Fax model only
G3TX TX image signal at the selected speed
Detail To close DC circuit and send the selected G3 signal pattern at the selected speed using the G3
signal sending function of modem.
Adj/Set/Operate Method
Select the setting value
Display/Adj/Set Range
300bps, 2400bps, 4800bps, 7200bps, 9600bps, TC7200, TC9600, 12000bps, 14400bps
Supplement/Memo
Fax model only
DTMFTX TX DTMF by DTMF send func of Modem
Detail To close DC circuit and send the DTMF signal using DTMF sending function of modem.
Adj/Set/Operate Method
Select the item
Supplement/Memo
Fax model only
V34G3TX TX img sgl at the selected speed (V.34)
Detail To close DC circuit and send the image signal at selected speed and modulation speed (baud rate)
using G3 signal sending function (V.34) of modem.
Adj/Set/Operate Method
Select the setting value
Display/Adj/Set Range
SPEED: 2400bps, 3429baud, 3200baud, 3000baud, 2800baud, 2743baud, 2400baud
Supplement/Memo
Fax model only
● RELAY-1
TESTMODE (Service mode for test print, operation check, etc.) > FAX (FAX test mode) > MODEM > RELAY-1
H Test relays and port switch of NCU
Detail To test ON/OFF of relays and port switch of NCU.
Adj/Set/Operate Method
Select the item
Supplement/Memo
Fax model only
■ FACULTY
TESTMODE (Service mode for test print, operation check, etc.) > FAX (FAX test mode) > FACULTY
G34800TX TX 4800bps by G3 sgl send func of Modem
Detail To close DC circuit and send frequency (4800bps) using G3 signal sending function of modem.
Adj/Set/Operate Method
Select the item
Supplement/Memo
Fax model only
