Canon imageCLASS MF264dw - Removing the SADF Motor

■ Procedure
CAUTION:
Do not damage the White Guide Plate.
1.
5x
1x
Removing the SADF Motor
■ Preparation
1. “Removing the Cartridge” on page 77
2. “ Removing the Left Cover” on page 80
3. “Removing the SADF Unit + Reader Unit” on page 126
4. “Separating the SADF Unit + Reader Unit” on page 129
4. Parts Replacement and Cleaning
135
