Pickup Feed Delivery System
Removing the Pickup Roller
■ Preparation
1. “Removing the Cartridge” on page 77
■ Procedure
CAUTION:
Do not touch the surface of the roller with bare hands, as doing so will attach skin oil on it and decrease feedability.
1.
2.
Removing the Separation Pad Unit
■ Preparation
1. “Removing the Cartridge” on page 77
4. Parts Replacement and Cleaning
211
To Next Page
